全自動鋁條折彎機折彎角度偏差的解決方法可歸納為以下四點，需結合設備檢查與參數調整：

　　The solution to the bending angle deviation of the fully automatic aluminum strip bending machine can be summarized into the following four points, which need to be combined with equipment inspection and parameter adjustment:

　　檢查模具磨損與安裝精度

　　Check mold wear and installation accuracy

　　模具長期使用可能磨損，需定期檢查并更換損壞部件。

　　The mold may wear out after long-term use and requires regular inspection and replacement of damaged parts.

　　確保模具安裝水平，避免因傾斜導致折彎角度偏差。

　　Ensure that the mold is installed horizontally to avoid bending angle deviation caused by tilting.

　　調整液壓系統壓力與平衡機構

　　Adjust the hydraulic system pressure and balance mechanism

　　檢查液壓系統是否正常工作，壓力油是否均勻進入左右油缸。

　　Check if the hydraulic system is working properly and if the pressure oil is evenly flowing into the left and right cylinders.

　　若使用電液伺服系統，需觀察光柵尺顯示的下行深度變化。

　　If using an electro-hydraulic servo system, it is necessary to observe the downward depth change displayed on the grating ruler.

　　校準工作中心與補償參數

　　Calibration work center and compensation parameters

　　通過測量板材兩端誤差調整角度補償，中間誤差則通過撓度補償修正。

　　Adjust the angle compensation by measuring the error at both ends of the board, and correct the intermediate error through deflection compensation.

　　確保滑塊與工作臺平行度符合標準要求。

　　Ensure that the parallelism between the slider and the workbench meets the standard requirements.

　　檢查同步機構與連桿連接

　　Check the connection between the synchronization mechanism and the connecting rod

　　若折彎角度不一致，需檢查連桿是否脫開或連接處打滑。

　　If the bending angle is not consistent, it is necessary to check whether the connecting rod is detached or if the connection is slipping.

　　對于大角度折彎（≥90°），可使用角度尺輔助測量并微調連桿位置。

　　For large angle bending (≥ 90 °), an angle ruler can be used to assist in measuring and fine-tuning the position of the connecting rod.

　　操作建議 ：優先通過系統參數調整（如撓度/角度補償）快速修正，若問題持續則需拆解檢查機械部件（如同步機構、液壓系統）。若調整無效，建議聯系廠家保修服務。

　　Operation suggestion: Prioritize quick correction through system parameter adjustment (such as deflection/angle compensation). If the problem persists, disassemble and inspect mechanical components (such as synchronization mechanisms and hydraulic systems). If the adjustment is ineffective, it is recommended to contact the manufacturer's warranty service.
